Now let's take a closer look at each specific SfB Server 2015 role and their functions. Together, these would be enough to provide the SME with A/V & Web Conferencing, IM & Presence, Application Sharing and Enterprise Voice. To this they could add an Edge Server for external connectivity and a SIP-PSTN Gateway to enable Enterprise Voice. Hence, an SME could typically deploy SfB Server 2015 Standard Edition on a single server that acts as a Front End Server, with additional collocated roles such as Mediation Server, Persistent Chat Server, Monitoring and Archiving Server. SfB Server 2015 Standard Edition also supports Front End Pool pairing, which adds some resiliency across multiple servers and sites. SfB Server 2015 Standard Edition offers a relatively low cost entry point based on that all components can be hosted on a single server with the addition of an Edge Server if external connectivity is required. For example, the Standard Edition automatically installs SQL Server Express with the Front End Server and uses this database to store Skype information.
#Microsoft lync 2013 books full#
SfB Server 2015 Enterprise Edition requires full SQL on a dedicated Back End SQL Server or Pool.Īlternatively, SME's who want to introduce unified communications to their organisation might use SfB Server 2015 Standard Edition that can combine several roles onto one server. For example, a large organisation requiring high-availability might use SfB Server 2015 Enterprise Edition and deploy the Front End role across multiple servers in a Front End Pool along with several mirrored Back End SQL Servers for the database in a Back End SQL Pool. When combined across multiple servers they are called a Pool. Some of these roles can be combined on multiple servers to provide fault tolerance and high-availability. SfB Server 2015 is modular and made-up of several specific roles. Hence, Enterprise Edition requires more investment and higher specification components compared to Standard Edition. Whilst features between the two versions are similar, Enterprise Edition provides options for more scalability along with high-availability and disaster recovery that are not supported in Standard Edition. These two versions allow a variety of deployment options depending on the organisations requirements and budget. Skype for Business Server 2015 is available in two versions, Standard Edition and Enterprise Edition. These consist of various systems such as servers and their operating systems, databases, authentication and authorising systems, networking systems and infrastructure as well as telephone PBX systems. SfB Server 2015 relies on a number of external components in order to function. Please see: Part 3: Networks & Protocols used by Skype for Business 2015 - (Lync 2013). However, we will specifically look at traffic and protocols used in A/V Conferencing and Application Sharing in a separate the paper in this series. It intentionally does not show the traffic and protocols within the SfB On-Premise environment between the various Servers and their roles. The diagram also provides an indication of the external traffic and protocols through the Edge Pool, Reverse Proxy and ADFS Proxy into the Skype for Business environment. The above diagram shows the servers in a typical On-Premise Skype for Business 2015 deployment that supports video conferencing, web and audio conferencing, VIS, instant messaging (IM), application sharing and PBX replacement and/or integration. It is recommended that you look all the papers listed below for a background into Skype for Business and a detailed explanation about the Codecs, Protocols, Procedures and some of the available solutions Whilst Lync 2013 has now been renamed Skype for Business 2015, it is generally backwards compatible with Lync Server 2013. The paper is specifically based on Skype for Business 2015. Within these papers, the terms Lync, Skype, Skype for Business and SfB, unless stated otherwise, all refer to Skype for Business Server 2015.
With reference to the On-Premise deployment diagram, we will show all the Skype for Business 2015 servers and discuss each server's roles and functions with the aim of helping you to determine what actual servers you need for your specific Skype for Business deployment.
Hence, it will focus on the communications used in A/V Conferencing and Application Sharing.
#Microsoft lync 2013 books series#
This paper shows the Skype® for Business 2015 - (Lync® 2013) Servers in a typical On-Premise deployment and discusses the Roles and their Functions as Part 2 of a series that specifically looks at Microsoft Skype for Business 2015 (Lync 2013) and the challenges and solutions for integrating Skype for Business 2015 with H.323 or SIP standards compliant videoconferencing systems.
